Description
Analog Input
Burn-out Detection
- Yes
Input Range
- ±15 mV, ±50 mV, ±100 mV, ±500 mV, ±1 V, ±2.5 V, 0~15 mV, 0~50 mV, 0~100 mV, 0~500 mV, 0~1 V, 0~2.5 V
Communications
Interface
- RS-485, Micro USB
Environment
Isolation Voltage
- 3,000 VDC
Operating Temperature
- -40~85 °C (-40~185 °F)
General
Connectors
- 2 x 10-pin plug-in screw terminal
Protocol
- ASCII command, Modbus/RTU
Power Requirements
Input Voltage
- 10~48 VDC
Thermocouple Input
Channels
- 8
Input Type
- mA, mV, V, T/C: J, K, T, E, R, S, B, N type
Resolution
- 16-bit
Sample Range
- 100 S/s (sum)
Temperature Range
- Type J (0~760° C), Type K (0~1370° C), Type T (-100~400° C), Type E (0~1000° C), Type R (500~1750° C), Type S (500~1750° C), Type B (500~1800° C), Type N (-200~1300° C)
Hardware
Certification
- CE, FCC
